Промышленные газовые пружины - толкающего типа
Официальный сайт ACE / ACE Controls (США): www.ace-ace.com
Доставка Промышленные газовые пружины - толкающего типа ACE / ACE Controls по России.
Мы поставляем полную линейку продукции и запчастей компании ACE / ACE Controls предприятиям по всей России.
Для запроса цен и сроков поставки, пожалуйста, заполните форму обратной связи или пришлите описание необходимых Вам наименований на электронный адрес G.Hermescompany@gmail.com
Преимущества доставки промышленного оборудования ООО «Золотой Гермес»:
- Оперативно доставляем оборудование в любую точку РФ.
- Предоставляется официальная гарантия завода-изготовителя.
- Соблюдаем регламент Таможенного Союза и законодательство России.
- Прямые поставки от заводов и минимальная торговая наценка.
Описание Промышленные газовые пружины - толкающего типа
Промышленные газовые пружины - толкающего типа ACE / ACE Controls
|
ACE GS-10-20 "Extension force max. 100 N Piston rod diameter O 3 mm Progression Approx. 29 % to 33 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: coated steel, Piston rod: stainless steel (1.4301/1.4305, AISI 304/303),… Подробнее... |
|
|
ACE GS-10-30 "Extension force max. 100 N Piston rod diameter O 3 mm Progression Approx. 29 % to 33 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: coated steel, Piston rod: stainless steel (1.4301/1.4305, AISI 304/303),… Подробнее... |
|
|
ACE GS-10-80 "Extension force max. 100 N Piston rod diameter O 3 mm Progression Approx. 13 % to 16 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: coated steel, Piston rod: stainless steel (1.4301/1.4305, AISI 304/303),… Подробнее... |
|
|
ACE GS-12-100 "Extension force max. 120 N Piston rod diameter O 4 mm Progression Approx. 20 % to 35 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: coated steel, Piston rod: stainless steel (1.4301/1.4305, AISI 304/303),… Подробнее... |
|
ACE GS-12-120-V4A "Extension force max. 100 N Piston rod diameter O 4 mm Progression Approx. 20 % to 25 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-12-150 "Extension force max. 150 N Piston rod diameter O 4 mm Progression Approx. 20 % to 35 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: coated steel, Piston rod: stainless steel (1.4301/1.4305, AISI 304/303),… Подробнее... |
|
|
ACE GS-12-150-V4A "Extension force max. 150 N Piston rod diameter O 4 mm Progression Approx. 20 % to 25 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-12-50-V4A "Extension force max. 180 N Piston rod diameter O 4 mm Progression Approx. 20 % to 25 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-12-60 "Extension force max. 150 N Piston rod diameter O 4 mm Progression Approx. 20 % to 35 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: coated steel, Piston rod: stainless steel (1.4301/1.4305, AISI 304/303),… Подробнее... |
|
|
ACE GS-12-60-V4A "Extension force max. 150 N Piston rod diameter O 4 mm Progression Approx. 20 % to 25 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-12-80-V4A "Extension force max. 150 N Piston rod diameter O 4 mm Progression Approx. 20 % to 25 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-15-100 "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 30 % to 40 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-15-100-V4A "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 28 % to 42 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-15-120 "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 30 % to 40 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-15-120-V4A "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 28 % to 42 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-15-150 "Extension force max. 350 N Piston rod diameter O 6 mm Progression Approx. 30 % to 40 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-15-150-V4A "Extension force max. 700 N Piston rod diameter O 8 mm Progression Approx. 28 % to 32 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-15-20 "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 30 % to 40 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-15-200 "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 30 % to 40 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-15-20-V4A "Extension force max. 150 N Piston rod diameter O 4 mm Progression Approx. 20 % to 25 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-15-20-VA "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 30 % to 53 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4301/1.4305, AISI 304/303)… Подробнее... |
|
|
ACE GS-15-40 "Extension force max. 120 N Piston rod diameter O 4 mm Progression Approx. 20 % to 35 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: coated steel, Piston rod: stainless steel (1.4301/1.4305, AISI 304/303),… Подробнее... |
|
|
ACE GS-15-40-V4A "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 28 % to 42 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-15-40-VA "Extension force max. 5,000 N Piston rod diameter O 20 mm Progression Approx. 42 % to 44 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-15-50 "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 30 % to 40 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-15-50-V4A "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 28 % to 42 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-15-50-VA "Extension force max. 4,150 N Piston rod diameter O 20 mm Progression Approx. 42 % to 44 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-15-60-VA "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 30 % to 53 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4301/1.4305, AISI 304/303)… Подробнее... |
|
|
ACE GS-15-80 "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 30 % to 40 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-15-80-V4A "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 28 % to 42 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-15-80-VA "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 30 % to 53 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4301/1.4305, AISI 304/303)… Подробнее... |
|
|
ACE GS-19-100 "Extension force max. 700 N Piston rod diameter O 8 mm Progression Approx. 24 % to 35 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-19-100-V4A "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 28 % to 42 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-19-100-VA "Extension force max. 700 N Piston rod diameter O 8 mm Progression Approx. 28 % to 32 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4301/1.4305, AISI 304/303)… Подробнее... |
|
|
ACE GS-19-150 "Extension force max. 700 N Piston rod diameter O 8 mm Progression Approx. 24 % to 35 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-19-150-VA "Extension force max. 700 N Piston rod diameter O 8 mm Progression Approx. 28 % to 32 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4301/1.4305, AISI 304/303)… Подробнее... |
|
|
ACE GS-19-200 "Extension force max. 600 N Piston rod diameter O 8 mm Progression Approx. 24 % to 35 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-19-200-V4A "Extension force max. 700 N Piston rod diameter O 8 mm Progression Approx. 28 % to 32 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-19-250 "Extension force max. 450 N Piston rod diameter O 8 mm Progression Approx. 24 % to 35 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-19-300 "Extension force max. 700 N Piston rod diameter O 8 mm Progression Approx. 24 % to 35 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-19-300-VA "Extension force max. 700 N Piston rod diameter O 8 mm Progression Approx. 28 % to 32 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4301/1.4305, AISI 304/303)… Подробнее... |
|
|
ACE GS-19-50 "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 30 % to 40 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-19-50-VA "Extension force max. 400 N Piston rod diameter O 6 mm Progression Approx. 30 % to 53 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4301/1.4305, AISI 304/303)… Подробнее... |
|
|
ACE GS-22-100 "Extension force max. 1,300 N Piston rod diameter O 10 mm Progression Approx. 30 % to 40 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-22-100-V4A "Extension force max. 1,200 N Piston rod diameter O 10 mm Progression Approx. 30 % to 33 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-22-150 "Extension force max. 1,300 N Piston rod diameter O 10 mm Progression Approx. 30 % to 40 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-22-150-V4A "Extension force max. 1,200 N Piston rod diameter O 10 mm Progression Approx. 30 % to 33 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
|
|
ACE GS-22-200-VA "Extension force max. 1,200 N Piston rod diameter O 10 mm Progression Approx. 29 % to 33 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4301/1.4305, AISI 304/303)… Подробнее... |
|
|
ACE GS-22-250 "Extension force max. 1,300 N Piston rod diameter O 10 mm Progression Approx. 30 % to 40 % Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Material Outer body: steel coated with UV paint, Piston rod: steel with wear-resistant coating,… Подробнее... |
|
|
ACE GS-22-250-V4A "Extension force max. 1,100 N Piston rod diameter O 10 mm Progression Approx. 30 % to 33 % Lifetime Approx. 10.000 m Operating temperature range -20 °C to +80 °C Material Outer body, Piston rod, End fittings: stainless steel (1.4404/1.4571, AISI 316L/316Ti)… Подробнее... |
