Тяжелые промышленные амортизаторы
Официальный сайт ACE / ACE Controls (США): www.ace-ace.com
Доставка Тяжелые промышленные амортизаторы ACE / ACE Controls по России.
Мы поставляем полную линейку продукции и запчастей компании ACE / ACE Controls предприятиям по всей России.
Для запроса цен и сроков поставки, пожалуйста, заполните форму обратной связи или пришлите описание необходимых Вам наименований на электронный адрес G.Hermescompany@gmail.com
Преимущества доставки промышленного оборудования ООО «Золотой Гермес»:
- Оперативно доставляем оборудование в любую точку РФ.
- Предоставляется официальная гарантия завода-изготовителя.
- Соблюдаем регламент Таможенного Союза и законодательство России.
- Прямые поставки от заводов и минимальная торговая наценка.
Описание Тяжелые промышленные амортизаторы
Тяжелые промышленные амортизаторы ACE / ACE Controls
|
ACE CA2X10EU-1 "Energy capacity 18,000 Nm/cycle Energy capacity 2,200,000 Nm/h Energy capacity with air/oil tank 2,700,000 Nm/h Effective weight min. 9,100 kg Effective weight max. 27,200 kg Return Force min. 160 N Return Force max. 460 N Return Time 0.80 s Side Load… Подробнее... |
|
|
ACE CA2X10EU-1F "Energy capacity 14,500 Nm/cycle Energy capacity 1,900,000 Nm/h Energy capacity with air/oil tank 2,400,000 Nm/h Effective weight min. 7,200 kg Effective weight max. 21,700 kg Return Force min. 230 N Return Force max. 650 N Return Time 0.70 s Side Load… Подробнее... |
|
|
ACE CA2X10EU-1SM "Energy capacity 14,500 Nm/cycle Energy capacity 1,900,000 Nm/h Energy capacity with air/oil tank 2,400,000 Nm/h Effective weight min. 2,900 kg Effective weight max. 8,700 kg Return Force min. 230 N Return Force max. 650 N Return Time 0.70 s Side Load… Подробнее... |
|
|
ACE CA2X10EU-2 "Energy capacity 18,000 Nm/cycle Energy capacity 2,200,000 Nm/h Energy capacity with air/oil tank 2,700,000 Nm/h Effective weight min. 22,600 kg Effective weight max. 68,000 kg Return Force min. 160 N Return Force max. 460 N Return Time 0.80 s Side Load… Подробнее... |
|
|
ACE CA2X10EU-2F "Energy capacity 14,500 Nm/cycle Energy capacity 1,900,000 Nm/h Energy capacity with air/oil tank 2,400,000 Nm/h Effective weight min. 18,000 kg Effective weight max. 54,400 kg Return Force min. 230 N Return Force max. 650 N Return Time 0.70 s Side Load… Подробнее... |
|
|
ACE CA2X10EU-2SM "Energy capacity 18,000 Nm/cycle Energy capacity 2,200,000 Nm/h Energy capacity with air/oil tank 2,700,000 Nm/h Effective weight min. 22,600 kg Effective weight max. 68,000 kg Return Force min. 160 N Return Force max. 460 N Return Time 0.80 s Side Load… Подробнее... |
|
|
ACE CA2X10EU-3 "Energy capacity 18,000 Nm/cycle Energy capacity 2,200,000 Nm/h Energy capacity with air/oil tank 2,700,000 Nm/h Effective weight min. 56,600 kg Effective weight max. 170,000 kg Return Force min. 160 N Return Force max. 460 N Return Time 0.80 s Side Load… Подробнее... |
|
|
ACE CA2X10EU-3F "Energy capacity 14,500 Nm/cycle Energy capacity 1,900,000 Nm/h Energy capacity with air/oil tank 2,400,000 Nm/h Effective weight min. 45,300 kg Effective weight max. 136,000 kg Return Force min. 230 N Return Force max. 650 N Return Time 0.70 s Side Load… Подробнее... |
|
|
ACE CA2X10EU-3SM "Energy capacity 18,000 Nm/cycle Energy capacity 2,200,000 Nm/h Energy capacity with air/oil tank 2,700,000 Nm/h Effective weight min. 56,600 kg Effective weight max. 170,000 kg Return Force min. 160 N Return Force max. 460 N Return Time 0.80 s Side Load… Подробнее... |
|
|
ACE CA2X10EU-4 "Energy capacity 18,000 Nm/cycle Energy capacity 2,200,000 Nm/h Energy capacity with air/oil tank 2,700,000 Nm/h Effective weight min. 3,600 kg Effective weight max. 11,000 kg Return Force min. 160 N Return Force max. 460 N Return Time 0.80 s Side Load… Подробнее... |
|
|
ACE CA2X10EU-4F "Energy capacity 18,000 Nm/cycle Energy capacity 2,200,000 Nm/h Energy capacity with air/oil tank 2,700,000 Nm/h Effective weight min. 3,600 kg Effective weight max. 11,000 kg Return Force min. 160 N Return Force max. 460 N Return Time 0.80 s Side Load… Подробнее... |
|
|
ACE CA2X10EU-4SM "Energy capacity 14,125 Nm/cycle Energy capacity 2,260,000 Nm/h Energy capacity with air/oil tank 2,800,000 Nm/h Effective weight min. 2,900 kg Effective weight max. 8,700 kg Return Force min. 270 N Return Force max. 710 N Return Time 0.6 s Side Load… Подробнее... |
|
|
ACE CA2X2EU-1 "Energy capacity 3,600 Nm/cycle Energy capacity 1,100,000 Nm/h Energy capacity with air/oil tank 1,350,000 Nm/h Effective weight min. 1,800 kg Effective weight max. 5,400 kg Return Force min. 210 N Return Force max. 285 N Return Time 0.25 s Side Load… Подробнее... |
|
|
ACE CA2X2EU-1F "Energy capacity 18,000 Nm/cycle Energy capacity 2,200,000 Nm/h Energy capacity with air/oil tank 2,700,000 Nm/h Effective weight min. 9,100 kg Effective weight max. 27,200 kg Return Force min. 160 N Return Force max. 460 N Return Time 0.80 s Side Load… Подробнее... |
|
|
ACE CA2X2EU-1SM "Energy capacity 3,600 Nm/cycle Energy capacity 1,100,000 Nm/h Energy capacity with air/oil tank 1,350,000 Nm/h Effective weight min. 1,800 kg Effective weight max. 5,400 kg Return Force min. 210 N Return Force max. 285 N Return Time 0.25 s Side Load… Подробнее... |
|
|
ACE CA2X2EU-2F "Energy capacity 18,000 Nm/cycle Energy capacity 2,200,000 Nm/h Energy capacity with air/oil tank 2,700,000 Nm/h Effective weight min. 22,600 kg Effective weight max. 68,000 kg Return Force min. 160 N Return Force max. 460 N Return Time 0.80 s Side Load… Подробнее... |
|
|
ACE CA2X2EU-2SM "Energy capacity 3,600 Nm/cycle Energy capacity 1,100,000 Nm/h Energy capacity with air/oil tank 1,350,000 Nm/h Effective weight min. 4,500 kg Effective weight max. 13,400 kg Return Force min. 210 N Return Force max. 285 N Return Time 0.25 s Side Load… Подробнее... |
|
|
ACE CA2X2EU-3 "Damping torque 4 - 40 Nm Damping direction left Return Damping Torque 4 Nm Construction size O 80 mm Lifetime 50,000 cycles, even after this time, the dampers still produce over approx. 80 % of their original damping moment. The service life may be significantly… Подробнее... |
|
|
ACE CA2X2EU-3F "Energy capacity 18,000 Nm/cycle Energy capacity 2,200,000 Nm/h Energy capacity with air/oil tank 2,700,000 Nm/h Effective weight min. 56,600 kg Effective weight max. 170,000 kg Return Force min. 160 N Return Force max. 460 N Return Time 0.80 s Side Load… Подробнее... |
|
|
ACE CA2X2EU-3R "Energy capacity 18,000 Nm/cycle Energy capacity 2,200,000 Nm/h Energy capacity with air/oil tank 2,700,000 Nm/h Effective weight min. 56,600 kg Effective weight max. 170,000 kg Return Force min. 160 N Return Force max. 460 N Return Time 0.80 s Side Load… Подробнее... |
|
|
ACE CA2X2EU-4F "Energy capacity 3,600 Nm/cycle Energy capacity 1,100,000 Nm/h Energy capacity with air/oil tank 1,350,000 Nm/h Effective weight min. 700 kg Effective weight max. 2,200 kg Return Force min. 210 N Return Force max. 285 N Return Time 0.25 s Side Load Angle… Подробнее... |
|
|
ACE CA2X4EU-1 "Energy capacity 3,600 Nm/cycle Energy capacity 1,100,000 Nm/h Energy capacity with air/oil tank 1,350,000 Nm/h Effective weight min. 1,800 kg Effective weight max. 5,400 kg Return Force min. 210 N Return Force max. 285 N Return Time 0.25 s Side Load… Подробнее... |
|
|
ACE CA2X4EU-1F "Energy capacity 3,600 Nm/cycle Energy capacity 1,100,000 Nm/h Energy capacity with air/oil tank 1,350,000 Nm/h Effective weight min. 1,800 kg Effective weight max. 5,400 kg Return Force min. 210 N Return Force max. 285 N Return Time 0.25 s Side Load… Подробнее... |
|
|
ACE CA2X4EU-1SM "Energy capacity 3,600 Nm/cycle Energy capacity 1,100,000 Nm/h Energy capacity with air/oil tank 1,350,000 Nm/h Effective weight min. 1,800 kg Effective weight max. 5,400 kg Return Force min. 210 N Return Force max. 285 N Return Time 0.25 s Side Load… Подробнее... |
|
|
ACE CA2X4EU-2F "Energy capacity 3,600 Nm/cycle Energy capacity 1,100,000 Nm/h Energy capacity with air/oil tank 1,350,000 Nm/h Effective weight min. 4,500 kg Effective weight max. 13,400 kg Return Force min. 210 N Return Force max. 285 N Return Time 0.25 s Side Load… Подробнее... |
|
|
ACE CA2X4EU-2SM "Energy capacity 3,600 Nm/cycle Energy capacity 1,100,000 Nm/h Energy capacity with air/oil tank 1,350,000 Nm/h Effective weight min. 4,500 kg Effective weight max. 13,400 kg Return Force min. 210 N Return Force max. 285 N Return Time 0.25 s Side Load… Подробнее... |
|
|
ACE CA2X4EU-3R "Energy capacity 7,200 Nm/cycle Energy capacity 1,350,000 Nm/h Energy capacity with air/oil tank 1,700,000 Nm/h Effective weight min. 22,600 kg Effective weight max. 68,000 kg Return Force min. 150 N Return Force max. 285 N Return Time 0.50 s Side Load… Подробнее... |
|
|
ACE CA2X4EU-3SM "Energy capacity 7,200 Nm/cycle Energy capacity 1,350,000 Nm/h Energy capacity with air/oil tank 1,700,000 Nm/h Effective weight min. 22,600 kg Effective weight max. 68,000 kg Return Force min. 150 N Return Force max. 285 N Return Time 0.50 s Side Load… Подробнее... |
|
|
ACE CA2X4EU-4 "Energy capacity 10,800 Nm/cycle Energy capacity 1,600,000 Nm/h Energy capacity with air/oil tank 2,000,000 Nm/h Effective weight min. 5,400 kg Effective weight max. 16,300 kg Return Force min. 150 N Return Force max. 400 N Return Time 0.60 s Side Load… Подробнее... |
|
|
ACE CA2X4EU-4R "Energy capacity 10,800 Nm/cycle Energy capacity 1,600,000 Nm/h Energy capacity with air/oil tank 2,000,000 Nm/h Effective weight min. 2,200 kg Effective weight max. 6,500 kg Return Force min. 150 N Return Force max. 400 N Return Time 0.60 s Side Load… Подробнее... |
|
|
ACE CA2X6EU-1SM "Energy capacity 10,800 Nm/cycle Energy capacity 1,600,000 Nm/h Energy capacity with air/oil tank 2,000,000 Nm/h Effective weight min. 5,400 kg Effective weight max. 16,300 kg Return Force min. 150 N Return Force max. 400 N Return Time 0.60 s Side Load… Подробнее... |
|
|
ACE CA2X6EU-2 "Energy capacity 10,800 Nm/cycle Energy capacity 1,600,000 Nm/h Energy capacity with air/oil tank 2,000,000 Nm/h Effective weight min. 13,600 kg Effective weight max. 40,800 kg Return Force min. 150 N Return Force max. 400 N Return Time 0.60 s Side Load… Подробнее... |
|
|
ACE CA2X6EU-2SM "Energy capacity 10,800 Nm/cycle Energy capacity 1,600,000 Nm/h Energy capacity with air/oil tank 2,000,000 Nm/h Effective weight min. 13,600 kg Effective weight max. 40,800 kg Return Force min. 150 N Return Force max. 400 N Return Time 0.60 s Side Load… Подробнее... |
|
|
ACE CA2X6EU-3F "Energy capacity 10,800 Nm/cycle Energy capacity 1,600,000 Nm/h Energy capacity with air/oil tank 2,000,000 Nm/h Effective weight min. 34.000 kg Effective weight max. 102,000 kg Return Force min. 150 N Return Force max. 400 N Return Time 0.60 s Side Load… Подробнее... |
|
|
ACE CA2X6EU-3R "Energy capacity 7,200 Nm/cycle Energy capacity 1,350,000 Nm/h Energy capacity with air/oil tank 1,700,000 Nm/h Effective weight min. 22,600 kg Effective weight max. 68,000 kg Return Force min. 150 N Return Force max. 285 N Return Time 0.50 s Side Load… Подробнее... |
|
|
ACE CA2X6EU-3SM "Energy capacity 7,200 Nm/cycle Energy capacity 1,350,000 Nm/h Energy capacity with air/oil tank 1,700,000 Nm/h Effective weight min. 22,600 kg Effective weight max. 68,000 kg Return Force min. 150 N Return Force max. 285 N Return Time 0.50 s Side Load… Подробнее... |
|
|
ACE CA2X6EU-4 "Energy capacity 14,500 Nm/cycle Energy capacity 1,900,000 Nm/h Energy capacity with air/oil tank 2,400,000 Nm/h Effective weight min. 2,900 kg Effective weight max. 8,700 kg Return Force min. 230 N Return Force max. 650 N Return Time 0.70 s Side Load… Подробнее... |
|
|
ACE CA2X6EU-4F "Energy capacity 14,500 Nm/cycle Energy capacity 1,900,000 Nm/h Energy capacity with air/oil tank 2,400,000 Nm/h Effective weight min. 2,900 kg Effective weight max. 8,700 kg Return Force min. 230 N Return Force max. 650 N Return Time 0.70 s Side Load… Подробнее... |
|
|
ACE CA2X6EU-4R "Energy capacity 10,800 Nm/cycle Energy capacity 1,600,000 Nm/h Energy capacity with air/oil tank 2,000,000 Nm/h Effective weight min. 2,200 kg Effective weight max. 6,500 kg Return Force min. 150 N Return Force max. 400 N Return Time 0.60 s Side Load… Подробнее... |
|
|
ACE CA2X6EU-4SM "Energy capacity 14,500 Nm/cycle Energy capacity 1,900,000 Nm/h Energy capacity with air/oil tank 2,400,000 Nm/h Effective weight min. 2,900 kg Effective weight max. 8,700 kg Return Force min. 230 N Return Force max. 650 N Return Time 0.70 s Side Load… Подробнее... |
|
|
ACE CA2X8EU-1 "Energy capacity 10,800 Nm/cycle Energy capacity 1,600,000 Nm/h Energy capacity with air/oil tank 2,000,000 Nm/h Effective weight min. 5,400 kg Effective weight max. 16,300 kg Return Force min. 150 N Return Force max. 400 N Return Time 0.60 s Side Load… Подробнее... |
|
|
ACE CA2X8EU-1F "Energy capacity 14,500 Nm/cycle Energy capacity 1,900,000 Nm/h Energy capacity with air/oil tank 2,400,000 Nm/h Effective weight min. 7,200 kg Effective weight max. 21,700 kg Return Force min. 230 N Return Force max. 650 N Return Time 0.70 s Side Load… Подробнее... |
|
|
ACE CA2X8EU-1SM "Energy capacity 10,800 Nm/cycle Energy capacity 1,600,000 Nm/h Energy capacity with air/oil tank 2,000,000 Nm/h Effective weight min. 5,400 kg Effective weight max. 16,300 kg Return Force min. 150 N Return Force max. 400 N Return Time 0.60 s Side Load… Подробнее... |
|
|
ACE CA2X8EU-2 "Energy capacity 10,800 Nm/cycle Energy capacity 1,600,000 Nm/h Energy capacity with air/oil tank 2,000,000 Nm/h Effective weight min. 13,600 kg Effective weight max. 40,800 kg Return Force min. 150 N Return Force max. 400 N Return Time 0.60 s Side Load… Подробнее... |
|
|
ACE CA2X8EU-2F "Energy capacity 14,500 Nm/cycle Energy capacity 1,900,000 Nm/h Energy capacity with air/oil tank 2,400,000 Nm/h Effective weight min. 18,000 kg Effective weight max. 54,400 kg Return Force min. 230 N Return Force max. 650 N Return Time 0.70 s Side Load… Подробнее... |
|
|
ACE CA2X8EU-2SM "Energy capacity 10,800 Nm/cycle Energy capacity 1,600,000 Nm/h Energy capacity with air/oil tank 2,000,000 Nm/h Effective weight min. 13,600 kg Effective weight max. 40,800 kg Return Force min. 150 N Return Force max. 400 N Return Time 0.60 s Side Load… Подробнее... |
|
|
ACE CA2X8EU-3F "Energy capacity 14,500 Nm/cycle Energy capacity 1,900,000 Nm/h Energy capacity with air/oil tank 2,400,000 Nm/h Effective weight min. 45,300 kg Effective weight max. 136,000 kg Return Force min. 230 N Return Force max. 650 N Return Time 0.70 s Side Load… Подробнее... |
|
|
ACE CA2X8EU-3SM "Energy capacity 10,800 Nm/cycle Energy capacity 1,600,000 Nm/h Energy capacity with air/oil tank 2,000,000 Nm/h Effective weight min. 34.000 kg Effective weight max. 102,000 kg Return Force min. 150 N Return Force max. 400 N Return Time 0.60 s Side Load… Подробнее... |
|
|
ACE CA2X8EU-4 "Energy capacity 18,000 Nm/cycle Energy capacity 2,200,000 Nm/h Energy capacity with air/oil tank 2,700,000 Nm/h Effective weight min. 3,600 kg Effective weight max. 11,000 kg Return Force min. 160 N Return Force max. 460 N Return Time 0.80 s Side Load… Подробнее... |
|
|
ACE CA2X8EU-4F "Energy capacity 18,000 Nm/cycle Energy capacity 2,200,000 Nm/h Energy capacity with air/oil tank 2,700,000 Nm/h Effective weight min. 3,600 kg Effective weight max. 11,000 kg Return Force min. 160 N Return Force max. 460 N Return Time 0.80 s Side Load… Подробнее... |
