Описание Промышленные амортизаторы
Промышленные амортизаторы ACE / ACE Controls
|
ACE MA3350EUM "Energy capacity 680 Nm/cycle Energy capacity 112,000 Nm/h Effective weight min. 25,854 kg Effective weight max. 44,225 kg Return Force max. 242 N Return Force min. 47 N Return Time 1.0 s Side Load Angle max. 3 ° Impact velocity range 0.02 m/s to 0.46… Подробнее... |
|
|
ACE MA4550EUM "Energy capacity 850 Nm/cycle Energy capacity 112,000 Nm/h Energy capacity with oil recirculation 248,000 Nm/h Energy capacity with air/oil tank 192,000 Nm/h Effective weight min. 5,000 kg Effective weight max. 180,000 kg Return Force max. 145 N Return… Подробнее... |
|
|
ACE MA64100EUM "Energy capacity 6,780 Nm/cycle Energy capacity 248,000 Nm/h Energy capacity with oil recirculation 644,000 Nm/h Energy capacity with air/oil tank 497,000 Nm/h Effective weight min. 330 kg Effective weight max. 80,000 kg Return Force max. 365 N Return… Подробнее... |
|
|
ACE MA64150EUM "Energy capacity 2,275 Nm/cycle Energy capacity 146,000 Nm/h Energy capacity with oil recirculation 384,000 Nm/h Energy capacity with air/oil tank 293,000 Nm/h Effective weight min. 220 kg Effective weight max. 50,000 kg Return Force max. 155 N Return… Подробнее... |
|
|
ACE MA6450EUM "Energy capacity 850 Nm/cycle Energy capacity 112,000 Nm/h Energy capacity with oil recirculation 248,000 Nm/h Energy capacity with air/oil tank 192,000 Nm/h Effective weight min. 5,000 kg Effective weight max. 180,000 kg Return Force max. 145 N Return… Подробнее... |
|
|
ACE MC3325EUM-0 "Energy capacity 170 Nm/cycle Energy capacity 75,000 Nm/h Energy capacity with oil recirculation 169,000 Nm/h Energy capacity with air/oil tank 124,000 Nm/h Effective weight min. 9 kg Effective weight max. 40 kg Return Force max. 90 N Return Force min.… Подробнее... |
|
ACE MC3325EUM-0-HT "Energy capacity 170 Nm/cycle Energy capacity at 20 °C 215,000 Nm/h Energy capacity at 100 °C 82,000 Nm/h Effective weight min. 9 kg Effective weight max. 40 kg Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request.… Подробнее... |
|
|
ACE MC3325EUM-1 "Energy capacity 170 Nm/cycle Energy capacity 75,000 Nm/h Energy capacity with oil recirculation 169,000 Nm/h Energy capacity with air/oil tank 124,000 Nm/h Effective weight min. 30 kg Effective weight max. 120 kg Return Force max. 90 N Return Force min.… Подробнее... |
|
|
ACE MC3325EUM-1-HT "Energy capacity 170 Nm/cycle Energy capacity at 20 °C 215,000 Nm/h Energy capacity at 100 °C 82,000 Nm/h Effective weight min. 30 kg Effective weight max. 120 kg Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request.… Подробнее... |
|
|
ACE MC3325EUM-1-V4A "Energy capacity 5,650 Nm/cycle Energy capacity 248,000 Nm/h Energy capacity with oil recirculation 644,000 Nm/h Energy capacity with air/oil tank 497,000 Nm/h Effective weight min. 4,700 kg Effective weight max. 18,800 kg Return Force max. 365 N Return… Подробнее... |
|
|
ACE MC3325EUM-2 "Energy capacity 170 Nm/cycle Energy capacity 75,000 Nm/h Energy capacity with oil recirculation 169,000 Nm/h Energy capacity with air/oil tank 124,000 Nm/h Effective weight min. 100 kg Effective weight max. 420 kg Return Force max. 90 N Return Force… Подробнее... |
|
|
ACE MC3325EUM-2-HT "Energy capacity 3,730 Nm/cycle Energy capacity 192,000 Nm/h Effective weight min. 10,600 kg Effective weight max. 42,500 kg Return Force max. 270 N Return Force min. 105 N Return Time 0.34 s Side Load Angle max. 3 ° Impact velocity range 0.15 m/s to… Подробнее... |
|
|
ACE MC3325EUM-2-LT "Energy capacity 3,730 Nm/cycle Energy capacity at 20 °C 550,000 Nm/h Energy capacity at 100 °C 200,000 Nm/h Effective weight min. 3,150 kg Effective weight max. 12,600 kg Side Load Angle max. 3 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds… Подробнее... |
|
|
ACE MC3325EUM-2-V4A "Energy capacity 5,650 Nm/cycle Energy capacity 248,000 Nm/h Energy capacity with oil recirculation 644,000 Nm/h Energy capacity with air/oil tank 497,000 Nm/h Effective weight min. 16,000 kg Effective weight max. 63,700 kg Return Force max. 365 N Return… Подробнее... |
|
|
ACE MC3325EUM-3 "Energy capacity 170 Nm/cycle Energy capacity 75,000 Nm/h Energy capacity with oil recirculation 169,000 Nm/h Energy capacity with air/oil tank 124,000 Nm/h Effective weight min. 350 kg Effective weight max. 1,420 kg Return Force max. 90 N Return Force… Подробнее... |
|
|
ACE MC3325EUM-3-HT "Energy capacity 170 Nm/cycle Energy capacity at 20 °C 215,000 Nm/h Energy capacity at 100 °C 82,000 Nm/h Effective weight min. 350 kg Effective weight max. 1,420 kg Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request.… Подробнее... |
|
|
ACE MC3325EUM-3-V4A "Energy capacity 170 Nm/cycle Energy capacity 75,000 Nm/h Effective weight min. 350 kg Effective weight max. 1,420 kg Return Force max. 90 N Return Force min. 45 N Return Time 0.03 s Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other… Подробнее... |
|
|
ACE MC3325EUM-4 "Energy capacity 170 Nm/cycle Energy capacity 75,000 Nm/h Energy capacity with oil recirculation 169,000 Nm/h Energy capacity with air/oil tank 124,000 Nm/h Effective weight min. 9 kg Effective weight max. 40 kg Return Force max. 90 N Return Force min.… Подробнее... |
|
|
ACE MC3325EUM-4-HT "Energy capacity 170 Nm/cycle Energy capacity at 20 °C 215,000 Nm/h Energy capacity at 100 °C 82,000 Nm/h Effective weight min. 9 kg Effective weight max. 40 kg Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request.… Подробнее... |
|
|
ACE MC3325EUM-4-V4A "Energy capacity 330 Nm/cycle Energy capacity 85,000 Nm/h Effective weight min. 5 kg Effective weight max. 22 kg Return Force max. 135 N Return Force min. 45 N Return Time 0.06 s Side Load Angle max. 3 ° Impact velocity range 0.15 m/s to 5 m/s. Other… Подробнее... |
|
|
ACE MC3350EUM-0 "Energy capacity 170 Nm/cycle Energy capacity 75,000 Nm/h Energy capacity with oil recirculation 169,000 Nm/h Energy capacity with air/oil tank 124,000 Nm/h Effective weight min. 30 kg Effective weight max. 120 kg Return Force max. 90 N Return Force min.… Подробнее... |
|
|
ACE MC3350EUM-0-HT "Energy capacity 170 Nm/cycle Energy capacity at 20 °C 215,000 Nm/h Energy capacity at 100 °C 82,000 Nm/h Effective weight min. 30 kg Effective weight max. 120 kg Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request.… Подробнее... |
|
|
ACE MC3350EUM-0-LT "Energy capacity 330 Nm/cycle Energy capacity 85,000 Nm/h Effective weight min. 18 kg Effective weight max. 70 kg Return Time 0.16 s Side Load Angle max. 3 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request. Operating temperature range… Подробнее... |
|
|
ACE MC3350EUM-0-V4A "Energy capacity 170 Nm/cycle Energy capacity 75,000 Nm/h Effective weight min. 30 kg Effective weight max. 120 kg Return Force max. 90 N Return Force min. 45 N Return Time 0.03 s Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other… Подробнее... |
|
|
ACE MC3350EUM-1 "Energy capacity 170 Nm/cycle Energy capacity 75,000 Nm/h Energy capacity with oil recirculation 169,000 Nm/h Energy capacity with air/oil tank 124,000 Nm/h Effective weight min. 100 kg Effective weight max. 420 kg Return Force max. 90 N Return Force… Подробнее... |
|
|
ACE MC3350EUM-1-V4A "Energy capacity 170 Nm/cycle Energy capacity 75,000 Nm/h Effective weight min. 100 kg Effective weight max. 420 kg Return Force max. 90 N Return Force min. 45 N Return Time 0.03 s Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other… Подробнее... |
|
|
ACE MC3350EUM-2 "Energy capacity 170 Nm/cycle Energy capacity 75,000 Nm/h Energy capacity with oil recirculation 169,000 Nm/h Energy capacity with air/oil tank 124,000 Nm/h Effective weight min. 350 kg Effective weight max. 1,420 kg Return Force max. 90 N Return Force… Подробнее... |
|
|
ACE MC3350EUM-2-HT "Energy capacity 170 Nm/cycle Energy capacity at 20 °C 215,000 Nm/h Energy capacity at 100 °C 82,000 Nm/h Effective weight min. 350 kg Effective weight max. 1,420 kg Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request.… Подробнее... |
|
|
ACE MC3350EUM-2-V4A "Energy capacity 170 Nm/cycle Energy capacity 75,000 Nm/h Effective weight min. 350 kg Effective weight max. 1,420 kg Return Force max. 90 N Return Force min. 45 N Return Time 0.03 s Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other… Подробнее... |
|
|
ACE MC3350EUM-3 "Energy capacity 330 Nm/cycle Energy capacity 85,000 Nm/h Energy capacity with oil recirculation 180,000 Nm/h Energy capacity with air/oil tank 135,000 Nm/h Effective weight min. 5 kg Effective weight max. 22 kg Return Force max. 135 N Return Force min.… Подробнее... |
|
|
ACE MC3350EUM-3-V4A "Energy capacity 330 Nm/cycle Energy capacity 85,000 Nm/h Effective weight min. 5 kg Effective weight max. 22 kg Return Force max. 135 N Return Force min. 45 N Return Time 0.06 s Side Load Angle max. 3 ° Impact velocity range 0.15 m/s to 5 m/s. Other… Подробнее... |
|
|
ACE MC3350EUM-4-HT "Energy capacity 370 Nm/cycle Energy capacity at 20 °C 307,000 Nm/h Energy capacity at 100 °C 117,000 Nm/h Effective weight min. 7 kg Effective weight max. 27 kg Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request.… Подробнее... |
|
|
ACE MC3350EUM-4-LT "Energy capacity 330 Nm/cycle Energy capacity 85,000 Nm/h Effective weight min. 18 kg Effective weight max. 70 kg Return Time 0.16 s Side Load Angle max. 3 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request. Operating temperature range… Подробнее... |
|
|
ACE MC4525EUM-0 "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Energy capacity with oil recirculation 192,000 Nm/h Energy capacity with air/oil tank 158,000 Nm/h Effective weight min. 20 kg Effective weight max. 90 kg Return Force max. 100 N Return Force… Подробнее... |
|
|
ACE MC4525EUM-0-LT "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Effective weight min. 20 kg Effective weight max. 90 kg Return Time 0.08 s Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request. Operating temperature range… Подробнее... |
|
|
ACE MC4525EUM-0-V4A "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Effective weight min. 20 kg Effective weight max. 90 kg Return Force max. 100 N Return Force min. 70 N Return Time 0.03 s Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other… Подробнее... |
|
|
ACE MC4525EUM-1 "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Energy capacity with oil recirculation 192,000 Nm/h Energy capacity with air/oil tank 158,000 Nm/h Effective weight min. 80 kg Effective weight max. 310 kg Return Force max. 100 N Return Force… Подробнее... |
|
|
ACE MC4525EUM-1-HT "Energy capacity 330 Nm/cycle Energy capacity at 20 °C 244,000 Nm/h Energy capacity at 100 °C 93,000 Nm/h Effective weight min. 240 kg Effective weight max. 840 kg Side Load Angle max. 3 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request.… Подробнее... |
|
|
ACE MC4525EUM-1-LT "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Effective weight min. 80 kg Effective weight max. 310 kg Return Time 0.08 s Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request. Operating temperature range… Подробнее... |
|
|
ACE MC4525EUM-1-V4A "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Effective weight min. 80 kg Effective weight max. 310 kg Return Force max. 100 N Return Force min. 70 N Return Time 0.03 s Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other… Подробнее... |
|
|
ACE MC4525EUM-2 "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Energy capacity with oil recirculation 192,000 Nm/h Energy capacity with air/oil tank 158,000 Nm/h Effective weight min. 260 kg Effective weight max. 1,050 kg Return Force max. 100 N Return Force… Подробнее... |
|
|
ACE MC4525EUM-3-HT "Energy capacity 370 Nm/cycle Energy capacity at 20 °C 307,000 Nm/h Energy capacity at 100 °C 117,000 Nm/h Effective weight min. 7 kg Effective weight max. 27 kg Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request.… Подробнее... |
|
|
ACE MC4525EUM-3-LT "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Effective weight min. 890 kg Effective weight max. 3,540 kg Return Time 0.08 s Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request. Operating temperature… Подробнее... |
|
|
ACE MC4525EUM-3-V4A "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Effective weight min. 890 kg Effective weight max. 3,540 kg Return Force max. 100 N Return Force min. 70 N Return Time 0.03 s Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s.… Подробнее... |
|
|
ACE MC4525EUM-4 "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Energy capacity with oil recirculation 192,000 Nm/h Energy capacity with air/oil tank 158,000 Nm/h Effective weight min. 20 kg Effective weight max. 90 kg Return Force max. 100 N Return Force… Подробнее... |
|
|
ACE MC4525EUM-4-HT "Energy capacity 740 Nm/cycle Energy capacity at 20 °C 321,000 Nm/h Energy capacity at 100 °C 122,000 Nm/h Effective weight min. 13 kg Effective weight max. 54 kg Side Load Angle max. 3 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request.… Подробнее... |
|
|
ACE MC4525EUM-4-LT "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Effective weight min. 20 kg Effective weight max. 90 kg Return Time 0.08 s Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request. Operating temperature range… Подробнее... |
|
|
ACE MC4525EUM-4-V4A "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Effective weight min. 20 kg Effective weight max. 90 kg Return Force max. 100 N Return Force min. 70 N Return Time 0.03 s Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other… Подробнее... |
|
|
ACE MC4550EUM-0 "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Energy capacity with oil recirculation 192,000 Nm/h Energy capacity with air/oil tank 158,000 Nm/h Effective weight min. 80 kg Effective weight max. 310 kg Return Force max. 100 N Return Force… Подробнее... |
|
|
ACE MC4550EUM-0-LT "Energy capacity 370 Nm/cycle Energy capacity 107,000 Nm/h Effective weight min. 80 kg Effective weight max. 310 kg Return Time 0.08 s Side Load Angle max. 4 ° Impact velocity range 0.15 m/s to 5 m/s. Other speeds on request. Operating temperature range… Подробнее... |
