Гидравлические демпферы
Официальный сайт ACE / ACE Controls (США): www.ace-ace.com
Доставка Гидравлические демпферы ACE / ACE Controls по России.
Мы поставляем полную линейку продукции и запчастей компании ACE / ACE Controls предприятиям по всей России.
Для запроса цен и сроков поставки, пожалуйста, заполните форму обратной связи или пришлите описание необходимых Вам наименований на электронный адрес G.Hermescompany@gmail.com
Преимущества доставки промышленного оборудования ООО «Золотой Гермес»:
- Оперативно доставляем оборудование в любую точку РФ.
- Предоставляется официальная гарантия завода-изготовителя.
- Соблюдаем регламент Таможенного Союза и законодательство России.
- Прямые поставки от заводов и минимальная торговая наценка.
Описание Гидравлические демпферы
Гидравлические демпферы внешне схожи с промышленными газовыми пружинами ACE, однако выставлены в конечное положение и их работа осуществляется иным принципом. Они оснащены индивидуальными регуляторами скорости для тяги и усилий толкания, чтобы гарантировать максимальную гибкость и широкие возможности применения. Гидравлические демпферы используются как компенсаторы двигателей или элементы безопасности, при этом всегда можно с высокой точностью задать значение скорости сжатия и расширения и обеспечить контроль и синхронизацию движения в двух направлениях и компенсировать поворотные усилия.
Гидравлические демпферы ACE / ACE Controls
|
ACE DVC-32-100EU "Compression force min. 42 N Compression force max. 1,335 N Traction force min. 42 N Traction force max. 2,000 N Outer body diameter O 32 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly… Подробнее... |
|
|
ACE DVC-32-100EU-XX "Compression force min. 42 N Compression force max. 1,335 N Traction force min. 42 N Traction force max. 2,000 N Outer body diameter O 32 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly… Подробнее... |
|
|
ACE DVC-32-150EU-XX "Compression force max. 6,000 N Traction force max. 6,000 N Outer body diameter O 50 mm mm Piston rod diameter O 10 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly adjustable Positive stop External positive… Подробнее... |
|
|
ACE DVC-32-50EU Compression force min. 42 N Compression force max. 2,000 N Traction force min. 42 N Traction force max. 2,000 N Outer body diameter O 32 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly… Подробнее... |
|
|
ACE DVC-32-50EU-XX "Compression force min. 42 N Compression force max. 2,000 N Traction force min. 42 N Traction force max. 2,000 N Outer body diameter O 32 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly… Подробнее... |
|
ACE HB-12-10 "Compression force max. 180 N Traction force max. 180 N Outer body diameter O 12 mm mm Piston rod diameter O 4 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 21 % of stroke. Separator piston - Operating… Подробнее... |
|
|
ACE HB-12-20 "Compression force max. 180 N Traction force max. 180 N Outer body diameter O 12 mm mm Piston rod diameter O 4 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 21 % of stroke. Separator piston - Operating… Подробнее... |
|
|
ACE HB-12-30 "Compression force max. 180 N Traction force max. 180 N Outer body diameter O 12 mm mm Piston rod diameter O 4 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 21 % of stroke. Separator piston - Operating… Подробнее... |
|
|
ACE HB-12-40 "Compression force max. 180 N Traction force max. 180 N Outer body diameter O 12 mm mm Piston rod diameter O 4 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 21 % of stroke. Separator piston - Operating… Подробнее... |
|
|
ACE HB-12-50 "Compression force max. 180 N Traction force max. 180 N Outer body diameter O 12 mm mm Piston rod diameter O 4 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 21 % of stroke. Separator piston - Operating… Подробнее... |
|
|
ACE HB-12-60 "Compression force max. 180 N Traction force max. 180 N Outer body diameter O 12 mm mm Piston rod diameter O 4 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 21 % of stroke. Separator piston - Operating… Подробнее... |
|
|
ACE HB-12-70 "Compression force max. 180 N Traction force max. 180 N Outer body diameter O 12 mm mm Piston rod diameter O 4 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 21 % of stroke. Separator piston - Operating… Подробнее... |
|
|
ACE HB-15-150 "Compression force max. 1,800 N Traction force max. 1,800 N Outer body diameter O 23 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-15-75 "Compression force max. 350 N Traction force max. 800 N Outer body diameter O 15.6 mm mm Piston rod diameter O 6 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston Extension… Подробнее... |
|
|
ACE HB-22-100 "Compression force max. 1,800 N Traction force max. 1,800 N Outer body diameter O 23 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-22-150 "Compression force max. 1,000 N Traction force max. 1,800 N Outer body diameter O 23 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-22-200 "Compression force max. 1,800 N Traction force max. 1,800 N Outer body diameter O 23 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-22-250 "Compression force max. 3,000 N Traction force max. 3,000 N Outer body diameter O 28 mm mm Piston rod diameter O 10 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-28-100 "Compression force max. 1,800 N Traction force max. 1,800 N Outer body diameter O 23 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-28-150 "Compression force max. 1,000 N Traction force max. 1,800 N Outer body diameter O 23 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-28-250 "Compression force max. 3,000 N Traction force max. 3,000 N Outer body diameter O 28 mm mm Piston rod diameter O 10 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-28-300 "Compression force max. 2,000 N Traction force max. 3,000 N Outer body diameter O 28 mm mm Piston rod diameter O 10 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-28-400 "Compression force max. 1,000 N Traction force max. 3,000 N Outer body diameter O 28 mm mm Piston rod diameter O 10 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-40-100 "Compression force max. 2,000 N Traction force max. 3,000 N Outer body diameter O 28 mm mm Piston rod diameter O 10 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-40-150 "Compression force max. 10,000 N Traction force max. 10,000 N Outer body diameter O 40 mm mm Piston rod diameter O 14 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-40-200 "Compression force max. 1,000 N Traction force max. 3,000 N Outer body diameter O 28 mm mm Piston rod diameter O 10 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-40-500 "Compression force max. 10,000 N Traction force max. 10,000 N Outer body diameter O 40 mm mm Piston rod diameter O 14 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-40-700 "Compression force max. 3,000 N Traction force max. 10,000 N Outer body diameter O 40 mm mm Piston rod diameter O 14 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-70-300 "Compression force max. 3,000 N Traction force max. 10,000 N Outer body diameter O 40 mm mm Piston rod diameter O 14 mm Lifetime Approx. 10,000 m Free travel Construction of the damper results in a free travel of approx. 20 % of stroke. Separator piston… Подробнее... |
|
|
ACE HB-70-800 "Compression force min. 30 N Compression force max. 3,500 N Return Force min. 15 N Return Force max. 30 N Return Time 0.2 s Side Load Angle max. 3 Подробнее... |
|
ACE HBD-50-150 "Compression force min. 42 N Compression force max. 1,335 N Traction force min. 42 N Traction force max. 2,000 N Outer body diameter O 32 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly… Подробнее... |
|
|
ACE HBD-50-250 "Compression force max. 1,400 N Traction force max. 6,000 N Outer body diameter O 50 mm mm Piston rod diameter O 10 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly adjustable Positive stop External positive… Подробнее... |
|
|
ACE HBD-50-50 "Compression force max. 6,000 N Traction force max. 6,000 N Outer body diameter O 50 mm mm Piston rod diameter O 10 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly adjustable Positive stop External positive… Подробнее... |
|
|
ACE HBD-70-100 "Compression force max. 10,000 N Traction force max. 10,000 N Outer body diameter O 70 mm mm Piston rod diameter O 14 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly adjustable Positive stop External positive… Подробнее... |
|
|
ACE HBD-70-150 "Compression force max. 10,000 N Traction force max. 10,000 N Outer body diameter O 70 mm mm Piston rod diameter O 14 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly adjustable Positive stop External positive… Подробнее... |
|
|
ACE HBD-70-200 "Compression force max. 1,400 N Traction force max. 6,000 N Outer body diameter O 50 mm mm Piston rod diameter O 10 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly adjustable Positive stop External positive… Подробнее... |
|
|
ACE HBD-70-400 "Compression force max. 10,000 N Traction force max. 10,000 N Outer body diameter O 70 mm mm Piston rod diameter O 14 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly adjustable Positive stop External positive… Подробнее... |
|
|
ACE HBD-70-500 "Compression force max. 50,000 N Traction force max. 50,000 N Outer body diameter O 85 mm mm Piston rod diameter O 20 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly adjustable Positive stop External positive… Подробнее... |
|
|
ACE HBD-85-150 "Compression force max. 20,000 N Traction force max. 50,000 N Outer body diameter O 85 mm mm Piston rod diameter O 20 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly adjustable Positive stop External positive… Подробнее... |
|
|
ACE HBD-85-200 "Compression force max. 10,000 N Traction force max. 50,000 N Outer body diameter O 85 mm mm Piston rod diameter O 20 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly adjustable Positive stop External positive… Подробнее... |
|
|
ACE HBD-85-300 "Compression force max. 50,000 N Traction force max. 50,000 N Outer body diameter O 85 mm mm Piston rod diameter O 20 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly adjustable Positive stop External positive… Подробнее... |
|
|
ACE HBD-85-500 "Compression force max. 20,000 N Traction force max. 50,000 N Outer body diameter O 85 mm mm Piston rod diameter O 20 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly adjustable Positive stop External positive… Подробнее... |
|
|
ACE HBD-85-600 "Compression force max. 10,000 N Traction force max. 50,000 N Outer body diameter O 85 mm mm Piston rod diameter O 20 mm Lifetime Approx. 10,000 m Operating temperature range 0 °C to 65 °C Adjustment Steplessly adjustable Positive stop External positive… Подробнее... |
|
|
ACE HBD-85-700 "Compression force max. 3,000 N Compression force with MBS max. 3,000 N Traction force max. 3,000 N Outer body diameter O 28 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Adjustment Achieved by… Подробнее... |
|
ACE HBS-28-100 "Compression force max. 900 N Compression force with MBS max. 3,000 N Traction force max. 3,000 N Outer body diameter O 28 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Adjustment Achieved by turning… Подробнее... |
|
|
ACE HBS-28-150 "Compression force max. 600 N Compression force with MBS max. 3,000 N Traction force max. 3,000 N Outer body diameter O 28 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Adjustment Achieved by turning… Подробнее... |
|
|
ACE HBS-28-200 "Compression force max. 3,000 N Compression force with MBS max. 3,000 N Traction force max. 3,000 N Outer body diameter O 28 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Adjustment Achieved by… Подробнее... |
|
|
ACE HBS-28-250 "Compression force max. 330 N Compression force with MBS max. 3,000 N Traction force max. 3,000 N Outer body diameter O 28 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Adjustment Achieved by turning… Подробнее... |
|
|
ACE HBS-28-300 "Compression force max. 900 N Compression force with MBS max. 3,000 N Traction force max. 3,000 N Outer body diameter O 28 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Adjustment Achieved by turning… Подробнее... |
|
|
ACE HBS-28-350 "Compression force max. 600 N Compression force with MBS max. 3,000 N Traction force max. 3,000 N Outer body diameter O 28 mm mm Piston rod diameter O 8 mm Lifetime Approx. 10,000 m Operating temperature range -20 °C to +80 °C Adjustment Achieved by turning… Подробнее... |
