Описание Демпферы профиля
Демпферы профиля ACE / ACE Controls
|
ACE TA12-5 "Energy capacity 6.0 Nm/cycle Energy capacity emergency use 9 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA17-7 "Energy capacity - Nm/cycle Energy capacity emergency use 2,701 Nm/cycle Depth thread hole min. 40 mm Energy absorption 91 % to 96 % Dynamic force range 37,138 N to 204,127 N Operating temperature range -40 °C to +90 °C, Co-polyester Elastomer -25 °C… Подробнее... |
|
|
ACE TA21-9 "Energy capacity 11.5 Nm/cycle Energy capacity emergency use 21 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA22-10 "Energy capacity 29.0 Nm/cycle Energy capacity emergency use 46 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA28-12 "Energy capacity 48.0 Nm/cycle Energy capacity emergency use 87 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA34-14 "Energy capacity 65.0 Nm/cycle Energy capacity emergency use 112 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA37-16 "Energy capacity 82.0 Nm/cycle Energy capacity emergency use 130 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA40-16 "Energy capacity 29.0 Nm/cycle Energy capacity emergency use 46 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA43-18 "Energy capacity 140.0 Nm/cycle Energy capacity emergency use 173 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA47-20 "Energy capacity 65.0 Nm/cycle Energy capacity emergency use 112 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA50-22 "Energy capacity 82.0 Nm/cycle Energy capacity emergency use 130 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA54-22 "Energy capacity 242.0 Nm/cycle Energy capacity emergency use 302 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA57-24 "Energy capacity 140.0 Nm/cycle Energy capacity emergency use 173 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA62-25 "Energy capacity 374.0 Nm/cycle Energy capacity emergency use 468 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA65-27 "Energy capacity 421.0 Nm/cycle Energy capacity emergency use 524 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA70-29 "Energy capacity 242.0 Nm/cycle Energy capacity emergency use 302 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA80-32 "Energy capacity 374.0 Nm/cycle Energy capacity emergency use 468 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA82-35 "Energy capacity 421.0 Nm/cycle Energy capacity emergency use 524 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA85-36 "Energy capacity 482.0 Nm/cycle Energy capacity emergency use 559 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position Material… Подробнее... |
|
|
ACE TA90-38 "Energy capacity 1,147.0 Nm/cycle Energy capacity emergency use 1,555 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position… Подробнее... |
|
|
ACE TA98-40 "Energy capacity 2,014.0 Nm/cycle Energy capacity emergency use 2,951 Nm/cycle Energy absorption 58 % to 73 % Dynamic force range 870 N to 90,000 N Operating temperature range -40 °C to +90 °C Construction size 12 mm to 116 mm Mounting in any position… Подробнее... |
|
ACE TR100-60 "Energy capacity 2.7 Nm/cycle Energy capacity emergency use 5.7 Nm/cycle Energy absorption 39 % to 62 % Dynamic force range 550 N to 21,200 N Operating temperature range -40 °C to +90 °C Construction size 30 mm to 102 mm Mounting in any position Material… Подробнее... |
|
|
ACE TR102-56H "Energy capacity 7.2 Nm/cycle Energy capacity emergency use 10.9 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position Material… Подробнее... |
|
|
ACE TR105-28HD "Energy capacity 8,457 Nm/cycle Energy capacity emergency use 11,840 Nm/cycle F max. static 639,100 N Energy absorption 43 % to 72 % Dynamic force range 78.800 N to 812,900 N Operating temperature range -40 °C to +90 °C Construction size 42 mm to 117… Подробнее... |
|
|
ACE TR117-30HD "Energy capacity max. 3.1 Nm/cycle Area 2,500 mm2 Return Time 4 s Standard density 200 Standard colour green Dimensions Widths: up to 1,500 mm Lengths: up to 5,000 mm Thicknesses: 12.5 mm and 25 mm Environment Resistant against ozone and UV radiation.… Подробнее... |
|
|
ACE TR143-86L-1 "Energy capacity 1,200.0 Nm/cycle Energy capacity emergency use 1,680.0 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position… Подробнее... |
|
|
ACE TR143-86L-2 "Energy capacity 1,800.0 Nm/cycle Energy capacity emergency use 2,520.0 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position… Подробнее... |
|
|
ACE TR143-86L-3 "Energy capacity 2,400.0 Nm/cycle Energy capacity emergency use 3,360.0 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position… Подробнее... |
|
|
ACE TR143-86L-4 "Energy capacity 3,000.0 Nm/cycle Energy capacity emergency use 4,200.0 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position… Подробнее... |
|
|
ACE TR143-86L-5 "Energy capacity 1,200.0 Nm/cycle Energy capacity emergency use 1,680.0 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position… Подробнее... |
|
|
ACE TR143-86L-6 "Energy capacity 1,800.0 Nm/cycle Energy capacity emergency use 2,520.0 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position… Подробнее... |
|
|
ACE TR143-86L-7 "Energy capacity 2,400.0 Nm/cycle Energy capacity emergency use 3,360.0 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position… Подробнее... |
|
|
ACE TR188-108L-1 "Energy capacity 3,000.0 Nm/cycle Energy capacity emergency use 4,200.0 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position… Подробнее... |
|
|
ACE TR188-108L-3 "Energy capacity 4,400.0 Nm/cycle Energy capacity emergency use 6,160.0 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position… Подробнее... |
|
|
ACE TR188-108L-4 "Energy capacity 5,500.0 Nm/cycle Energy capacity emergency use 7,700.0 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position… Подробнее... |
|
|
ACE TR188-108L-5 "Energy capacity 6,600.0 Nm/cycle Energy capacity emergency use 9,240.0 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position… Подробнее... |
|
|
ACE TR188-108L-7 "Energy capacity 4,400.0 Nm/cycle Energy capacity emergency use 6,160.0 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position… Подробнее... |
|
|
ACE TR29-17 "Energy capacity 2.3 Nm/cycle Energy capacity emergency use 5.4 Nm/cycle Energy absorption 25 % to 45 % Dynamic force range 218 N to 7,500 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 100 mm Mounting in any position Material… Подробнее... |
|
|
ACE TR29-17L "Energy capacity 158.0 Nm/cycle Energy capacity emergency use 261.0 Nm/cycle Energy absorption 39 % to 62 % Dynamic force range 550 N to 21,200 N Operating temperature range -40 °C to +90 °C Construction size 30 mm to 102 mm Mounting in any position Material… Подробнее... |
|
|
ACE TR30-15H "Energy capacity 6.0 Nm/cycle Energy capacity emergency use 18.0 Nm/cycle Energy absorption 39 % to 62 % Dynamic force range 550 N to 21,200 N Operating temperature range -40 °C to +90 °C Construction size 30 mm to 102 mm Mounting in any position Material… Подробнее... |
|
|
ACE TR37-22 "Energy capacity 3.5 Nm/cycle Energy capacity emergency use 8.1 Nm/cycle Energy absorption 25 % to 45 % Dynamic force range 218 N to 7,500 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 100 mm Mounting in any position Material… Подробнее... |
|
|
ACE TR39-19H "Energy capacity 92.0 Nm/cycle Energy capacity emergency use 122.0 Nm/cycle Energy absorption 25 % to 45 % Dynamic force range 218 N to 7,500 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 100 mm Mounting in any position Material… Подробнее... |
|
|
ACE TR42-14HD "Energy capacity 5,500.0 Nm/cycle Energy capacity emergency use 7,700.0 Nm/cycle Energy absorption 26 % to 41 % Dynamic force range 1,312 N to 217,700 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 188 mm Mounting in any position… Подробнее... |
|
|
ACE TR43-25 "Energy capacity 5.8 Nm/cycle Energy capacity emergency use 8.3 Nm/cycle Energy absorption 25 % to 45 % Dynamic force range 218 N to 7,500 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 100 mm Mounting in any position Material… Подробнее... |
|
|
ACE TR43-25L "Energy capacity 228.0 Nm/cycle Energy capacity emergency use 342.0 Nm/cycle Energy absorption 39 % to 62 % Dynamic force range 550 N to 21,200 N Operating temperature range -40 °C to +90 °C Construction size 30 mm to 102 mm Mounting in any position Material… Подробнее... |
|
|
ACE TR45-23H "Energy capacity 115.0 Nm/cycle Energy capacity emergency use 146.0 Nm/cycle Energy absorption 25 % to 45 % Dynamic force range 218 N to 7,500 N Operating temperature range -40 °C to +90 °C Construction size 29 mm to 100 mm Mounting in any position Material… Подробнее... |
|
|
ACE TR47-17HD "Energy capacity 1,634 Nm/cycle Energy capacity emergency use 2,288 Nm/cycle F max. static 304,500 N Energy absorption 43 % to 72 % Dynamic force range 78.800 N to 812,900 N Operating temperature range -40 °C to +90 °C Construction size 42 mm to 117 mm… Подробнее... |
|
|
ACE TR52-32H "Energy capacity 2.7 Nm/cycle Energy capacity emergency use 5.7 Nm/cycle Energy absorption 39 % to 62 % Dynamic force range 550 N to 21,200 N Operating temperature range -40 °C to +90 °C Construction size 30 mm to 102 mm Mounting in any position Material… Подробнее... |
|
|
ACE TR62-15HD "Energy capacity 850 Nm/cycle Energy capacity emergency use 1,190 Nm/cycle F max. static 122,100 N Energy absorption 43 % to 72 % Dynamic force range 78.800 N to 812,900 N Operating temperature range -40 °C to +90 °C Construction size 42 mm to 117 mm… Подробнее... |
|
|
ACE TR62-19HD "Energy capacity 1,634 Nm/cycle Energy capacity emergency use 2,288 Nm/cycle F max. static 304,500 N Energy absorption 43 % to 72 % Dynamic force range 78.800 N to 812,900 N Operating temperature range -40 °C to +90 °C Construction size 42 mm to 117 mm… Подробнее... |
